VEGAPULS 64 and 81
Set-up: Adjustment with signal conditioning instrument
→
…
→
Single measurement
OK
Reset MST1
OK
Delete MST1
OK
Reset?
OK
Reset now?
OK
Reset MST1
The input component for measurement loop 1
is hence reset. The menu reset MST1 appears
again.
→
Reset MST2
OK
Delete MST2
OK
Reset OK?
OK
Reset now OK?
OK
Reset MST2
The input component for measurement loop 2
is hence reset. The menu reset MST2 appears
again.
You have hence adjusted the default values
and deleted old adjustments.
ESC
Single measurement
ESC
Reset configuration
→
…
→
Reset sensor values
“Reset sensor values“ is not necessary and
cannot be enquired as you have also deleted
the sensor values with the measurement loop
reset.
→
Reset linearization curves
Here you can reset 1 … 3 linearization curves.
If you do not want to use new linearization
curves, you can be skipped and the reset
menu can be quit.
Quit reset menu
ESC
Reset VEGAMET
ESC
Additional functions
You are now again in the main menu stage
which is below the stage of the measured
value indication.
In the menu “
Configuration“ you now create
new measurement loops. The parameter ad-
justment menus cannot yet be enquired.
Configure measurement loop
→
…
→
Configuration
OK
Configuration inputs
→
…
→
Configuration measurement loop
OK
MST1 not configured
OK
Application not configured
+…–
Level
OK
Data will be saved
→
…
→
Sensor/Input, no sensor
+…–
Sensor/Input radar
OK
Sensor/Input radar
→
…
→
Kind not configured
+…–
Standard
OK
Standard
→
…
→
Option not determined
+…–
Option none
OK
Measurement loop is created
After some seconds the display indicates
“Option none“.
→
…
→
Sensor co-ordination
OK
+
A input 1
OK
A input 1
The statement of the position is important for
flow or differential measurements (linked appli-
cation. There are two sensor positions (A and
B). Each input must be co-ordinated to a posi-
tion. For pure level and distance measure-
ments the radar sensors are always co-
ordinated to input A.
Note:
If you work with a VEGAMET 515 V and you
have connected a second sensor, measure-
ment loop 2 must also be configured. Hence
push twice the key “ESC“ and MST1 level
appears.
→
MST2 not configured
Configure here measurement loop 2 (MST2)
like you proceeded for measurement loop 1
(configure measurement loop).
ESC
Sensor co-ordination
ESC
Measurement loop 1 level (or dis-
tance) or measurement loop 2 level
