64 VEGAPULS 64 and 81
• Hence hold the key “Strg“ or “CTRL“ pushed
and click to the sensor numbers which you
want to include in the sensor group to be
saved.
• Provide the sensor group with a name. In
the example “ OSSI2511.G01“.
• Enter in the field “ Backup notes“ some
additional backup information for easier co-
ordination of saved data later on.
• Click to “ Save“ and confirm the security
enquiry with “ yes“.
Save the data of the signal conditioning instru-
ments in the same way. Hence choose the
menu “ Services / Backup / Signal conditioning
instruments“.
Copy
Saved instrument dated can be enquired
again with the menu “ Services / Configuration“
and their adjustments can be used. In addition
the instrument data can be transmitted to new
sensors or signal conditioning instruments.
Set-up: Store and copy adjustment data
• Hence choose the menu “ Services / Restore
Configuration / Sensors“.
• In the menu window “ Restore Configuration“
you choose the appropriate backup file and
the sensor or the instruments the configura-
tion of which you want to restore.
• Click to “ Display all data bases“
• Choose the backup file.
• Choose in the left top corner the sensor, the
configuration of which you want to restore.
• Choose in the bottom left corner the instru-
ment number, the adjustments of which you
want to restore.
• Click to “ Restore to“.
