Velleman VMB1LED User Manual
Page 6
VMB1LED PWM LED strip dimmer Manual– edition 1_rev.2
6
OVERVIEW
Wiring
LED indication
1
LED strip
9
Power supply
2
LED strip power supply
10
Receiving Velbus data
3
Module or Velbus power supply
11
Sending Velbus data
4
Velbus
12
Operating mode
5
Pushbutton
13
Dim position (0 ~ 100%)
Settings
6
Address
7
Mode
8
Time
1
2
3
4
5
13
7
8
12
6
9
10
11
