VMB1LED PWM LED strip dimmer Manual– edition 1_rev.2

Set all atmospheres to maximum brightness

Remember the address of the dimmer module to reinstate it later on.

Set the address of the dimmer module to ‘81’. The MODE LED on the dimmer module will flash.

To set all linked atmospheres to full brightness, press and hold the manual control on the dimmer module until the
PWM LED lights up.

Reinstate the original address of the dimmer module.

1 sec

ADDR = 81

ADDR

Mode

Time

PWM

Learn
F1: OFF
E1: ON
D1: TGL
C1: DIM

B1: UP
A1: DWN
91: ATM
81: ADM

MODE

MAN(CLR)
