Depending on the setting of the ‘MODE’ rotary switch the directly connected pushbuttons or the learned ‘DIM’
Velbus pushbuttons will activate following function:
MODE Operating mode Description
0 Start/stop timer Pushing the pushbutton will switch on the LED strip. When the
set time (see ‘TIME’ switch) expires the LED strip is switched
off.
Pushing the pushbutton while the LED strip is already on will
switch it off immediately.
1 Staircase lighting timer Pushing the pushbutton will switch on the LED strip. When the
set time (see ‘TIME’ switch) expires the LED strip brightness
will slowly diminish to be completely off after 30 seconds.
Pushing the pushbutton while the LED strip is already on will
restart the timer.
2 Dimmer A short push will switch on the LED strip (full brightness).
Another short push when the LED strip is already on will switch
it off.
Push and hold will dim the LED strip up to maximum or down
to minimum brightness. The next push will dim in the opposite
direction When the set time (see ‘TIME’ switch) expires the
LED strip is switched off.
3 Dimmer with memory function A short push will switch on the LED strip (brightness as
memorized since last use). Another short push when the LED
strip is already on will switch it off.
Push and hold will dim the LED strip up to maximum or down
to minimum brightness. The next push will dim in the opposite
direction.
When the set time (see ‘TIME’ switch) expires the LED strip is
switched off.
4 Multiple position dimmer Pushing the pushbutton will switch on the LED strip (full
brightness). Every next push within 5 seconds after the
previous will change brightness by 25%.
When the LED strip is on and the previous push occurred more
than 5 seconds earlier, a push will switch off the LED strip.
When the set time (see ‘TIME’ switch) expires the LED strip is
switched off.
5 Slowly on dimmer Pushing the pushbutton will slowly turn on the LED strip to full
brightness. The duration to achieve maximum brightness is
determined by the ‘TIME’ switch.
Pushing the pushbutton while the LED strip is already on will
switch it off immediately.
6 Slowly off dimmer Pushing the pushbutton will switch on the LED strip to full
brightness.
Pushing the pushbutton when the LED strip is on will slowly
decrease brightness until the LED strip is off. The duration to
switch the LED strip to off is determined by the ‘TIME’ switch.
Pushing the pushbutton during decreasing brightness will turn
the LED strip back to full brightness.
7 Slowly on/off dimmer Pushing the pushbutton will slowly turn on the LED strip to full
brightness.
Pushing the pushbutton when the LED strip is on will slowly
decrease brightness until the LED strip is off.
The duration to achieve maximum brightness or to switch the
LED strip off is determined by the ‘TIME’ switch.
Remarks:
When the ‘TIME’ rotary switch is set to ‘0’ the dimmer module will always work in instant control, no matter what
operating mode is set. On other words, the LED strip will light up as long as the pushbutton is pushed.
When the ‘TIME’ rotary switch is set to ‘F’ the dimmer module will not automatically switch off or the dimming speed
will be maximal when the module is set to slowly on, slowly off or slowly on/off mode.
