Ranger RP
42
Settings in the menu
4.5.3 RESET – resetting terminal settings to the factory settings
4.6 Configuring interfaces (COMMUNICATION)
4.6.1 COM1/COM2 -> MODE – operating mode of the serial interface
SUrE? Confirmation inquiry
• Reset terminal settings to the factory settings with Yes
• Do not reset the terminal settings with No
Print Manual data output to the printer with PRINT
A.Print Automatic output of stable results to the printer (e. g. for series weighing operations)
CONtINU Ongoing output of all weight values via the interface
dIALOG Bi-directional communication via OHAUS or MT-SICS commands, control of the
scale via PC
CONt.OLd As per CONtINU, see above, but with 2 fixed blanks in front of the unit (compatible
with Spider 1/2/3)
dIAL.OLd As per dIALOG, see above, but with 2 fixed blanks in front of the unit (compatible
with Spider 1/2/3)
dt-b DigiTOL-compatible format.
GROSS • Transfer of the gross weight, identified with "G"
tArE
•
Transfer of the tare weight
nEt • Transfer of the net weight
dt-G As per dt-b, see above, gross weight identified with "G"
COnt-Wt
TOLEDO Continuous mode
COnt-Ct TOLEDO Continuous mode, transfer of the number of pieces
bArc.rd For connecting a serial bar code reader (automatically activates the 5-V voltage sup-
ply at Pin 9)
2nd.dISP For connecting a second display (automatically activates the 5-V voltage supply at
Pin 9)
rEF Data transfer from the reference scale (automatic switchover)
bULK Data transfer from the quantity scale (automatic switchover)
AuXILIA Data transfer from the reference or quantity scale (manual switchover)
