Ohaus RANGER ADVANCED COMPACT COUNTING SCALES Manual en - Manual (Page 38)

Ranger RP
38
Settings in the menu
4.4.2 ACCUMULATION – totalising
4.4.3 CHECKWEIGHING
PrINt Configure printout for accumulation
COM 1/COM 2 Select interface for the connected printer / computer
LOt.PrINt • Printout for each individual item
FIN.PrINt • Printout only at the end of accumulation
SUMMArY • Additional printout of the individual items after completion of accumulation
rEACH Z Reach a stable zero point between two items
ON • All load must first be removed from the scale before accumulation of the next item
is possible
OFF • No load removal requested between two items
bEEPEr Setting the beep for checkweighing
ON • A short beep sounds when the target value is reached
OFF • No beep
SP.tOL– Limit for activation of the I/O relay box. The value to be entered is the percentage
proportion of the lower tolerance of the target weight / target quantity.
EXAMPLE
Target weight:2000 g
tOLER+:2010 g
tOLER-:1990 g
SP.tOL-:010 (%)
The relay box is not activated until 199 g (= 10 % of 1990 g) is reached.
SENd.MOd Defines the form in which the scale sends information to the I/O relay box
CONtINU • Information is permanently sent
StAbLE • Information is only sent if the weight value is stable
