9

Gas sampling and gas conditioning technology

2-1.1.5.1-ME

Temperature control of the standard version takes place by means of an integrated capillary sensor
thermostat with excess temperature limiter and alarm function for insufficient temperature in a compact
arrangement directly on the probe. Test gas feeding is possible via an integrated check valve.


Additional functions of the SP2600-H..:

The calibration gas can be supplied directly at the check valve/C (return valve) to the probe

outlet. Calibration gas supply at the probe is possible without any expensive gas loss via the
otherwise open probe inlet.

The cut-off valve /I cuts off the gas outlet of the heated filter chamber.

The filter element, and via this indirectly, the filter space and sample tube or preliminary filter
can be back-flushed via the check valve /BB/F installed in the heated chamber wall.


9.1

OPTIONS

The following list shows the options available. The diversity of options and the modular design of the
M&C gas sample probes ensure optimum probe selection to suit the particular process and ambient
conditions.

Description

Part No.

Basic version SP2600-H/C/I/BB/F/0,1GF, heated up to 0-180 °C, with weatherproof
cover, material stainl. Steel 1.4571

20 S 3540

Basic version SP2600-H/C/I/BB/F/1K190, heated up to 0-180 °C, with weatherproof
cover, material stainl. Steel 1.4571

20 S 3550

Power supply 115V/60Hz /115V

20 S 9030

Type with back-flush/calibration gas valve (C*), opening pressure 0,7 bar,
Socket piece 6 mm*

20 S 9435

Type with PT100 sensor instead of capillary controller,
without thermostat /PT100

20 S 9025

Type with thermo-element Fe-CuNi (Typ J) instead of capillary controller,
without thermostat /Fe-CuNi

20 S 9027

Type with thermo-element Ni-CrNi (Typ K) instead of capillary controller,
without thermostat /Ni-CrNi

20 S 9028

Type with second PT100 sensor /2-PT100

20 S 9026

Type with special intermediate flange adapter DN..PN6 or ANSI..150 lbs /DN

20 S 9004

Type with gas pre-heater GVW1, material stainl. Steel 2-1.2.5 /GVW1

20 S 9058

Junction of the gas pre-

heater to the connection „BB“ and to the gas inlet /GVW

20 S 9062

Type with steam heating without thermostat and valves instead of the capillary
controller /D

20 S 9033
