Gas sampling and gas conditioning technology

2-1.1.7.2-ME

14.2

CONNECTION OF SAMPLE LINES

All connections for the sample lines are tube connectors out of stainl. steel suitable for connection of
stainl. steel tubes or hose pipes with dimension 1/4”. Only the outlet of the diluted sample gas and the
blow back

inlet is dimensioned for stainl. steel tube or flexible tube of 3/8”.

N O T E !

When connecting hose pipes to stainl. Steel fittings, a supporting sleeve
must always be used.
The connection must be checked for tightness.

N O T E !

In dependence on the water vapor content respectively the dew point of the
sample gas it is necessary to connect a heated sample line at the undiluted
sample gas outlet.


For connection of the sample lines, tube connectors with dimens

ion 1/4” or 3/8” are available. Please

act as follows:

Open the diagonal FRP-housing

Mount the hose pipe or tube to the respective fitting (see drawings in the annex)

Close the diagonal FRP-housing


14.3

CONNECTION OF DILUTION GAS, BYPASS GAS OR BLOW BACK

For

connection of the supply lines, tube connectors with dimension 1/4” and 3/8” are available. Please

act as follows:

Open the diagonal FRP-housing

Mount the hose pipe or tube to the respective fitting (see drawings in the annex)

Close the diagonal FRP-housing


When using the 19“-control panels –S or –S1, corresponding marked connectors for the supply gases
are provided at the rear of the unit.

14.4

CONNECTION OF CALIBRATION GAS

For all versions, a tube connector 1/4” is available for connection of the calibration gas.

Open the diagonal FRP-housing

Mount the hose pipe or tube to the respective fitting (see drawings in the annex)

Close the diagonal FRP-housing


When using the 19“ control panels –S or –S1, corresponding marked connectors for the supply gases
are provided at the rear of the unit.
