Gas sampling and gas conditioning technology 4-2.1.2-ME
Portable Sampling System Version PSS-10/1
(C) consumable parts, (R) recommended spare parts, (S) spare parts
recommended quantity
PSS-10/1 being in operation
[years]
C/R/S 1 2 3
Diverse:
90 G 0006 Pre-filter PF 2 for condensate pump SR25.1 C 5 10 15
90 K 6030 Fine fuse 4A
T
, 5mmx20mm for PSS... R 5 5 5
90 G 0020 Fine fuse 10A
T
, 5mmx20mm for PSS...
with option temp. controller and heated sample line
R 5 5 5
18 APPENDIX

Connecting the heated sample line with special adapter

Circuit diagram PSS-10/1, 115V and 230V
More product documentation is available on our Internet catalogue:
www.mc-techgroup.com

Instruction manual electric gas cooler ECP 20-2,
Document : 3.1.10-ME

Universal-Filters FP, FT, FPK, FS, FSS
Document : 5-1.1

Instruction manual diaphragm pump Series N
Document : 6-1.2.1-ME

Instruction manual peristaltic pump SR25.1, SR25.1-G,
Document : 3-7.1-ME

Liquid alarm sensor LA 1S,
Document : 5-5.1.1

Electronic Controllers LA-1.4,
Document : 5-5.1.2

Flow meter FM40
Document : 5-6.1.10

Ball valves L/PV-1
Document : 6-2.1.1

Temperature controller 701
Document : 2-5.1.2
