Gas sampling and gas conditioning technology 4-2.1.2-ME
17 SPARE PARTS LIST
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and are not binding.
For spare parts of components which are not presented in the following list please see the specific
instruction manuals or leaflets mentioned in the appendix.
Portable Sampling System Version PSS-10/1
(C) consumable parts, (R) recommended spare parts, (S) spare parts
recommended quantity
PSS-10/1 being in operation
[years]
C/R/S 1 2 3
Fine filter FP-2T:
90 F 0002 Filter element F-2T, PTFE, 2µm C 6 12 20
90 F 0040 Viton
®
O-ring, 26 for FP- R 1 1 1
90 F 0056 PVDF filter element clamp F-P S - - 1
90 F 0012 Filter body F-120G of glass R 1 1 1
Fine filter FP-2T with Option LA 1S:
90 F 0015 Filter body F-120G-D of glass
with GL25 condensate connection thread
R 1 1 1
90 F 0020 Union nut GL 25 R 1 1 1
90 F 0025 PTFE sealing ring GL 25-12mm Ø R 1 1 1
Peristaltic pump SR25.1:
90 P 1007 SR25 pump hose with PVDF tube connectors
DN 4/6mm
C 1 2 4
Diaphragm pump type N9 KPE/KP18
90 P 2200 Square cap type D9, 1/8“i for N9 KPE/KP18,
Material: PVDF S - - 1
90 P 2220 Diaphragm type S9, for N9 KPE/KP18,
Material: Viton
®
, PTFE coated
C 1 2 3
90 P 2211 Valve plate with seal for N9 KPE, 1 pc.,
material: Viton. (2 pcs./pump)
C 2 4 6
90 P 2205 Intermediate plate type Z9, for N9 KPE/KP18,
Material: PVDF
S - - 1
