2-1.3.9-ME Gas sampling and gas conditioning technology 7
Type Part-Nr. Material
Dimension
[mm]
Filter porosity[
m]
Filter in the probe:
S-3 SS150 90F0126 1.4404 150 x 30 2
S-2K150 90S0020 Ceramic Aerolith 150 x 30 2
Option spun glass cartridge FW
Filter FW (spun glass) 93S2083
Spun glass, high tempera-
ture resistant
Preliminary filters to be selected:
SP2000ST/V20-T 20S9315
PTFE needled felt (anti-
static)
450x40 3
SP2000ST/V12-1A-1 20S9559 Al
2
O
3
/SIC 500x40 1
SP2000ST/V20-0 20S9105 1.4404 200x50 3
SP2000ST/V20-0/HC 20S9115 Hastelloy x 200x50 3
SP2000ST/V20-1 20S9145 1.4404 500x60 3
SP2000ST/V20-1/HC 20S9155 Hastelloy x 500x60 3
SP2000ST/V20-1/HC 0,5μm 20S9156 Hastelloy x 500x60 0,5
SP2000ST/V20-3 20S9300 1.4404 1000/300x31 3
Table 2 Possible filters and preliminary filters for use inside the probe
The preliminary filters can be extended with the following extension tubes.
Extension [mm]
with volume displacer Art. no.
500 20S9165
1000 20S9170 Not suitable for pre-filter SP2000/V12-1A-1
1500 20S9175 Not suitable for pre-filter SP2000/V12-1A-1
Table 3 Extension tubes
8
OPTIONS
The following options are suitable for use in hazardous areas. Please read the identification for the respective
zone in table 4.
When selecting options, attention must be paid to the operating parameters.
