2-1.3.9-ME Gas sampling and gas conditioning technology 15
The intended use of the probe restricts the process medium temperature at the probe inlet and
the choice of options to the extent that the maximum surface temperature must lie below the
temperature limit given in table 5 for the combustible gases used or must correspond to the
temperature class of the combustible gases used.
Gas sample probe SP3200(V) for gas sampling out o f processes with combustible gases
Variants
Identification Max. medium tempera-
ture at the probe inlet [°C]
Max. surface temperature
[°C]
Temperature class
SP3200(V)/HEX5-x.08
and all options
II 3 G
T2 – T5
Corresponding to the
operating temperature of
the selected temperature
class for
the heating,
see table 4.1
T2 – T5
Corresponding to the
limiter temperature of the
selected temperature
class for the heating,
see table 4.1
T2 – T5
Corresponding to the
selected temperature
class for the heating,
see table 4.1
Table 4 Maximum surface temperatures for the use of heating HEX5-x.08
Temperature classes
T-Class ATEX
Cenelec/IEC/Nec 505 T-Class
NEC 500 Operating temperature
°C Limiter
°C
T2 T2 230 235
T2A 215 220
T3 T3 185 190
T3A 165 170
T3B 150 155
T3C 145 150
T4 T4 120 125
T4A 105 110
T5 T5 85 90
Table 5 Temperature classes for use of heating HEX5-x.08
10 RECEIPT OF GOODS AND STORAGE
 The probe and any special accessories should be unpacked carefully immediately upon delivery and
checked against the delivery note for completeness.
 The delivery should be checked for transport damage and the transport insurer notified immediately
of any damage.
 The gas sample probe is usually delivered in two packages:
- gas sample probe with the necessary fastening bolts, nuts and flange gasket;
- sample tube or preliminary filter – possibly with extension tube.
The probe should be stored in a room protected from frost!
11 PREPARATIONS FOR INSTALLATION
