IP Director Version 4.4 – User Manual – Part 2: Logging and Browsing

EVS Broadcast Equipment – March 2008

Issue 4.4.C

117

The New Search Filter window is displayed to allow the selection of the

filter’s criteria.

3.

Select the icon corresponding to the search criteria you want to add.

Each icon selected will add a line to the window to enable the search

criteria to be specified.

For more information on the operation of each individual filter, refer to the
section 3.6.4 “Search Options”, on page 94 in the Database Explorer
chapter.

4.

Click the Apply icon to store the search criteria selected.
The Search Filter Name window opens:

5.

Enter a name and a description into the Search Filter Name window.

The Search filter is now defined. It is applied to the Element List only if the
APPLY button is selected.

4.5.4 H

OW TO

A

PPLY A

S

EARCH IN

T

HE

M

INI

D

ATABASE

E

XPLORER

The display area for the Search Filters shows the list of search filters that have
been created.

To apply the required searches, check the box next to the filter to be applied and
select APPLY button.

The button will be coloured green when a search has been applied and the results

will be displayed in the Objects List area.

The button stays green if the list shown in the Element List area corresponds to
the selected search filters.

This button changes to red if the list shown in the Element List area doesn’t
correspond to the selected search filters. This occurs if the Search Filter selection
is changed and not applied.
