Issue 4.4.C IP Director Version 4.4 – User Manual – Part 2 – Logging and Browsing
EVS Broadcast Equipment – March 2008
88
3.5.7 H
OW TO
E
XPORT A
L
OGGING
P
ROFILE
F
ROM THE
T
REE
A logging profile used with a log sheet can be exported from the tree in XML
format.
To export a logging profile from the tree structure, proceed as follows:
• Right-clicking the log sheet for which the profile should be exported and select
Export Current Logging Profile from the contextual menu.
3.5.8 H
OW TO
P
RINT A
L
OG
S
HEET
A log sheet cannot be printed directly from the Database Explorer. The user must
proceed to the IP Logger application to initiate a printing.
3.5.9 L
OGS
D
ATA
C
OLUMN
H
EADINGS
Each log record in the result list is detailed in variable width columns providing
relevant information about the data stored with each log.
Column Name Description
Event Date Date of the log sheet as defined when it was created
Event Name of the log sheets defined when it was created.
Log Date Date as defined when the log sheet was created
Log T/C Captured T/C associated with the data which has been
entered on to the log
Description Free text entry description added by user
Level A rating can be given to a log from no stars to three stars
(***). This can be done at any time and can provide a useful
search filter for use in the Database Explorer.
Keyword The first five keywords associated with this log sheet
Parent Keyword The keywords associated globally to the entire log sheet. The
keywords defined in the second step of the ‘new log sheet
wizard’.
Associated
Clips
Any clips which have the T/C on the log within them, and that
have been made on the relevant recorder channels defined in
the log sheet.
Automatic
Keywords If automatic keywords have been defined in the logging profile
used with the log sheet, a column will appear for every
automatic keyword in the IP Logger list.
