ZyXEL G-560 User’s Guide
Chapter 6 Wireless Screens 79
Figure 45 Wireless Security: 802.1x
The following table describes the labels in this screen.
Table 18 Wireless Security: 802.1x
LABEL DESCRIPTION
Encryption Method Select 802.1x to configure authentication of wireless stations and encryption key
management.
Dynamic WEP
Key Exchange
Select Disable to allow wireless stations to communicate with the access points
without using dynamic WEP key exchange.
Select 64-bit WEP or 128-bit WEP to enable data encryption.
Up to 32 stations can access the G-560 when you configure dynamic WEP key
exchange.
Authentication
Server IP Address
Enter the IP address of the external authentication server in dotted decimal
notation.
Port Number Enter the port number of the external authentication server. The default port
number is 1812.
You need not change this value unless your network administrator instructs you to
do so with additional information.
Shared Secret Enter a password (up to 63 printable characters) as the key to be shared between
the external authentication server and the G-560.
The key must be the same on the external authentication server and your G-560.
The key is not sent over the network.
Apply Click Apply to save your changes back to the G-560.
Reset Click Reset to begin configuring this screen afresh.
