Chapter 7 Wireless Security Screen
ZyXEL NWA-1100 User’s Guide
82
Figure 36 Security: 802.1x Static 64-bit, 802.1x Static 128-bit (AP mode)
The following table describes the labels in this screen.
Table 19 Security: 802.1x Static 64-bit, 802.1x Static 128-bit
LABEL DESCRIPTION
Security Mode Choose 802.1x Static 64 or 802.1x Static 128 in this field.
Passphrase Enter the passphrase or string of text used for automatic WEP key generation on
wireless client adapters (AP mode).
Generate Click this to get the keys from the Passphrase you entered (AP mode).
Key 1 to Key 4 If you chose 802.1x Static 64, then enter any 5 characters (ASCII string) or 10
hexadecimal characters ("0-9", "A-F") preceded by 0x for each key.
If you chose 802.1x Static 128-bit, then enter 13 characters (ASCII string) or 26
hexadecimal characters ("0-9", "A-F") preceded by 0x for each key.
There are four data encryption keys to secure your data from eavesdropping by
unauthorized wireless users. The values for the keys must be set up exactly the
same on the access points as they are on the wireless stations.
The preceding “0x” is entered automatically. You must configure all four keys, but
only one key can be activated at any one time. The default key is key 1.
ReAuthentication
Timer
Specify how often wireless stations have to resend user names and passwords in
order to stay connected.
Enter a time interval between 10 and 9999 seconds. The default time interval is
1800 seconds (30 minutes). Alternatively, enter “0” to turn reauthentication off.
Note: If wireless station authentication is done using a
RADIUS server, the reauthentication timer on the
RADIUS server has priority.
