Chapter 7 Wireless Security Screen
ZyXEL NWA-1100 User’s Guide
79
The following table describes the labels in this screen.
7.4.2 Security: 802.1x Only
This screen varies depending on whether you select Access Point or Wireless Client in the
Wireless > Wireless Settings screen.
7.4.2.1 Access Point
Use this screen to use 802.1x-Only security mode for your ZyXEL Device that is in Access
Point operating mode. Select 802.1x-Only in the Security Mode field to display the following
screen.
Table 16 Security: WEP
LABEL DESCRIPTION
Security Mode Choose WEP in this field.
Authentication
Method
Select Open or Shared Key from the drop-down list box.
The default setting is Auto.
Data Encryption Select Disable to allow wireless stations to communicate with the access points
without any data encryption.
Select 64-bit WEP, 128-bit WEP or 152-bit WEP to enable data encryption.
Passphrase Enter the passphrase or string of text used for automatic WEP key generation on
wireless client adapters.
Generate Click this to get the keys from the Passphrase you entered.
Key 1 to
Key 4 The WEP keys are used to encrypt data. Both the ZyXEL Device and the wireless
stations must use the same WEP key for data transmission.
If you chose 64-bit WEP, then enter any 5 ASCII characters or 10 hexadecimal
characters ("0-9", "A-F").
If you chose 128-bit WEP, then enter 13 ASCII characters or 26 hexadecimal
characters ("0-9", "A-F").
If you chose 152-bit WEP, then enter 16 ASCII characters or 32 hexadecimal
characters ("0-9", "A-F").
You must configure all four keys, but only one key can be activated at any one
time. The default key is key 1.
Apply Click Apply to save your changes.
Reset Click Reset to begin configuring this screen afresh.
