Chapter 6 Wireless Settings Screen
ZyXEL NWA-1100 User’s Guide
70
6.4.4 AP + Bridge Mode
Use this screen to have the ZyXEL Device function as a bridge and access point
simultaneously. Select AP + Bridge as the Operation Mode. The following screen diplays.
Figure 30 Wireless: AP+Bridge
Enable Antenna
Diversity
Select this to use antenna diversity. Antenna diversity uses multiple antennas
to reduce signal interference.
Enable Spanning
Tree Protocol(STP)
(R)STP detects and breaks network loops and provides backup links between
switches, bridges or routers. It allows a bridge to interact with other (R)STP -
compliant bridges in your network to ensure that only one path exists between
any two stations on the network. Select the check box to activate STP on the
ZyXEL Device.
Table 11 Wireless: Bridge
LABEL DESCRIPTIONS
