Chapter 7 Wireless LAN
NBG-417N User’s Guide
91
7.8 WPS Screen
Use this screen to enable/disable WPS, view or generate a new PIN number and
check current WPS status. To open this screen, click Network > Wireless LAN >
WPS tab.
Figure 50 Network > Wireless LAN > WPS
The following table describes the labels in this screen.
Table 32 Network > Wireless LAN > WPS
LABEL DESCRIPTION
WPS Setup
Enable WPS
Select this to enable the WPS feature.
PIN Number This displays a PIN number last time system generated. Click Generate
to generate a new PIN number.
WPS Status
Status
This displays Configured when the NBG-417N has connected to a
wireless network using WPS or when Enable WPS is selected and
wireless or wireless security settings have been changed. The current
wireless and wireless security settings also appear in the screen.
This displays Unconfigured if WPS is disabled and there are no
wireless or wireless security changes on the NBG-417N or you click
Release_Configuration to remove the configured wireless and
wireless security settings.
Release
Configuration This button is only available when the WPS status displays Configured.
Click this button to remove all configured wireless and wireless security
settings for WPS connections on the NBG-417N.
Apply Click Apply to save your changes back to the NBG-417N.
Refresh Click Refresh to get this screen information afresh.
