Chapter 5 AP Mode
NBG-417N User’s Guide
55
The following table describes the labels shown in the Status screen.
Table 19 Status Screen (AP Mode)
LABEL DESCRIPTION
Device Information
System Name This is the System Name you enter in the Maintenance > System >
General screen. It is for identification purposes.
Firmware Version This is the firmware version and the date created.
LAN Information
- MAC Address
This shows the LAN Ethernet adapter MAC Address of your device.
- IP Address This shows the LAN port’s IP address.
- IP Subnet Mask This shows the LAN port’s subnet mask.
- DHCP This shows the LAN port’s DHCP role - None.
WLAN Information
- MAC Address
This shows the wireless adapter MAC Address of your device.
- Status This shows the current status of the Wireless LAN - On, Off or Off by
scheduler.
- Name (SSID) This shows a descriptive name used to identify the NBG-417N in the
wireless LAN.
- Channel This shows the channel number which you select manually.
- Operating Channel This shows the channel number which the NBG-417N is currently using
over the wireless LAN.
- Security Mode This shows the level of wireless security the NBG-417N is using.
- 802.11 Mode This shows the IEEE 802.11 standard that the NBG-417N supports.
Wireless clients must support the same standard in order to be able to
connect to the NBG-417N
- WPS This shows the WPS (WiFi Protected Setup) Status. Click the status to
display Network > Wireless LAN > WPS screen.
System Status
System Uptime This is the total time the NBG-417N has been on.
Current Date/Time This field displays your NBG-417N’s present date and time.
System Resource
- CPU Usage
This displays what percentage of the NBG-417N’s processing ability is
currently used. When this percentage is close to 100%, the NBG-417N is
running at full load, and the throughput is not going to improve anymore.
If you want some applications to have more throughput, you should turn
off other applications.
- Memory Usage This shows what percentage of the heap memory the NBG-417N is using.
Interface Status
Interface This displays the NBG-417N port types. The port types are: LAN and
WLAN.
Status For the LAN port, this field displays Down (line is down) or Up (line is up
or connected).
For the WLAN, it displays Up when the WLAN is enabled or Down when
the WLAN is disabled.
