Chapter 16 Bandwidth Management
NBG-417N User’s Guide
152
Note: This screen contains the Priority Queue and Bandwidth Allocation tables.
Though both tables are described in this section, you can only apply the rules in
one table. Fill out the table of the Bandwidth Management Type you selected
in
Section 16.4 on page 150
Click Management > Bandwidth MGMT > Advanced to open the bandwidth
management Advanced screen.
Figure 84 Management > Bandwidth MGMT > Advanced
The following table describes the labels in this screen.
Table 56 Management > Bandwidth MGMT > Advanced
LABEL DESCRIPTION
Priority Queue
Local IP
Address
Enter the IP address of the computer to which bandwidth management
does not apply.
Priority Queue Use this table to allocate specific amounts of bandwidth based on the
pre-defined service.
# This is the number of an individual bandwidth management rule.
Enable Select this check box to have the NBG-417N apply this bandwidth
management rule.
