Chapter 3 Introducing the Web Configurator
NBG-417N User’s Guide
34
3.5.2 Summary: DHCP Table
DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows
individual clients to obtain TCP/IP configuration at start-up from a server. You can
configure the NBG-417N’s LAN as a DHCP server or disable it. When configured as
a server, the NBG-417N provides the TCP/IP configuration for the clients. If DHCP
service is disabled, you must have another DHCP server on that network, or else
the computer must be manually configured.
Click the DHCP Table (Details...) hyperlink in the Status screen. Read-only
information here relates to your DHCP status. The DHCP table shows current
DHCP client information (including IP Address, Host Name and MAC Address)
of all network clients using the NBG-417N’s DHCP server.
Figure 6 Summary: DHCP Table
Remote
MGMT
WWW Use this screen to configure through which interface(s)
and from which IP address(es) users can use HTTP to
manage the NBG-417N.
UPnP General Use this screen to enable UPnP on the NBG-417N.
Maintenance
System General Use this screen to view and change administrative settings
such as system and domain names, password and
inactivity timer.
Time
Setting Use this screen to change your NBG-417N’s time and date.
Logs View Log Use this screen to view the logs for the categories that you
selected.
Tools Firmware Use this screen to upload firmware to your NBG-417N.
Configuratio
n Use this screen to backup and restore the configuration or
reset the factory defaults to your NBG-417N.
Restart This screen allows you to reboot the NBG-417N without
turning the power off.
Sys OP
Mode
General This screen allows you to select whether your device acts
as a Router or a Access Point.
Language This screen allows you to select the language you prefer.
Table 4 Screens Summary
LINK TAB FUNCTION
