Chapter 3 Introducing the Web Configurator
NBG-417N User’s Guide
32
3.5.1 Navigation Panel
Use the sub-menus on the navigation panel to configure NBG-417N features.
The following table describes the sub-menus.
- Firewall This shows whether the firewall is active or not.
- Bandwidth
Management
This shows whether bandwidth management is active or not.
- UPnP This shows whether UPnP is active or not.
Interface Status
Interface This displays the NBG-417N port types. The port types are: WAN, LAN
and WLAN.
Status For the LAN and WAN ports, this field displays Down (line is down) or Up
(line is up or connected).
For the WLAN, it displays Up when the WLAN is enabled or Down when
the WLAN is disabled.
Rate For the LAN ports, this displays the port speed and duplex setting or N/A
when the line is disconnected.
For the WAN port, it displays the port speed and duplex setting if you’re
using Ethernet encapsulation and Idle (line (ppp) idle), Dial (starting to
trigger a call) and Drop (dropping a call) if you're using PPPoE or PPTP
encapsulation. This field displays N/A when the line is disconnected.
For the WLAN, it displays the maximum transmission rate when the WLAN
is enabled and N/A when the WLAN is disabled.
Summary
DHCP Table Use this screen to view current DHCP client information.
Packet Statistics Use this screen to view port status and packet specific statistics.
WLAN Station Status Use this screen to view the wireless stations that are currently associated
to the NBG-417N.
Table 3 Web Configurator Status Screen (Router Mode) (continued)
LABEL DESCRIPTION
Table 4 Screens Summary
LINK TAB FUNCTION
Status This screen shows the NBG-417N’s general device, system
and interface status information. Use this screen to access
the wizard, and summary statistics tables.
Network
