Page 47
Chapter 4 Connection Wizard
NBG-417N User’s Guide
47
4.4.4 Your IP Address
The following wizard screen allows you to assign a fixed IP address or give the
NBG-417N an automatically assigned IP address depending on your ISP.
Figure 19 Wizard Step 3: Your IP Address
The following table describes the labels in this screen
Connection ID/
Name
Enter the connection ID or connection name in this field. It must follow
the "c:id" and "n:name" format. For example, C:12 or N:My ISP.
This field is optional and depends on the requirements of your ISP.
Get
automatically
from ISP
Select this radio button if your ISP did not assign you a fixed IP
address.
Use fixed IP
address
Select this radio button, provided by your ISP to give the NBG-417N a
fixed, unique IP address.
My IP
Address
Type the (static) IP address assigned to you by your ISP.
My IP Subnet
Mask
Type the subnet mask assigned to you by your ISP (if given).
Back
Click Back to return to the previous screen.
Next
Click Next to continue.
Exit
Click Exit to close the wizard screen without saving.
Table 13 Wizard Step 3: PPTP Connection
LABEL
DESCRIPTION
Table 14 Wizard Step 3: Your IP Address
LABEL
DESCRIPTION
Get automatically from
your ISP
Select this option If your ISP did not assign you a fixed IP
address. This is the default selection. If you choose this option,
skip directly to
Use fixed IP address
provided by your ISP
Select this option if you were given IP address and/or DNS server
settings by the ISP. The fixed IP address should be in the same
subnet as your broadband modem or router.
Back
Click Back to return to the previous screen.
Next
Click Next to continue.
Exit
Click Exit to close the wizard screen without saving.
