ZyXEL Communications NBG-417N - Manual (Page 59)

Chapter 5 AP Mode
NBG-417N User’s Guide
59
5.5 Logging in to the Web Configurator in AP
Mode
1 Connect your computer to the LAN port of the NBG-417N.
2 The default IP address of the NBG-417N is “192.168.1.2”. In this case, your
computer must have an IP address in the range between “192.168.1.3” and
“192.168.1.254”.
3 Click Start > Run on your computer in Windows.
4 Type “cmd” in the dialog box.
5 Type “ipconfig” to show your computer’s IP address. If your computer’s IP address
is not in the correct range then see
Appendix C on page 223 for information on
changing your computer’s IP address.
6 After you’ve set your computer’s IP address, open a web browser such as Internet
Explorer and type “192.168.1.2” as the web address in your web browser.
See Chapter 6 on page 61 for a tutorial on setting up a network with an AP.
