Chapter 16 Bandwidth Management
NBG-417N User’s Guide
151
The following table describes the labels in this screen.
16.5 Advanced Configuration
Use this screen to configure bandwidth managements rule for the pre-defined
services or applications.
Use this screen to configure bandwidth managements rule for specific protocols on
an IP or IP range.
Table 55 Management > Bandwidth MGMT > General
LABEL DESCRIPTION
Service Management
Bandwidth
Management
Type
This field allows you to have NBG-417N apply bandwidth
management.
Select Priority Queue or Bandwidth Allocation to enable
bandwidth management.
• Select Priority Queue to allocate bandwidth based on the pre-
defined priority assigned to an application. Refer to Section 16.5 on
page 151 .
• Select Bandwidth Allocation allocate specific amounts of
bandwidth to specific protocols on an IP or IP range. Refer to
Section 16.5 on page 151 .
Select Disable if you do not want to use this feature.
Total Bandwidth Setting. The fields below appear when you enable Bandwidth
Management.
Uplink
Type or select the total amount of bandwidth (from 64 Kbps to 30
Mbps) that you want to dedicate to uplink traffic.
If you type the amount of bandwidth, the selection automatically
becomes User Defined. If you select the amount of bandwidth, the
field automatically displays the value in Kbps.
This is traffic from LAN/WLAN to WAN.
Downlink Type or select the total amount of bandwidth (from 64 Kbps to 30
Mbps) that you want to dedicate to downlink traffic.
If you type the amount of bandwidth, the selection automatically
becomes User Defined. If you select the amount of bandwidth, the
field automatically displays the value in Kbps.
This is traffic from WAN to LAN/WLAN.
Apply Click Apply to save your customized settings.
Reset Click Reset to begin configuring this screen afresh.
