ZyXEL Communications 802.11g ADSL 2+ 4-Port Security Gateway HW-D Series - Manual (Page 77)

P-662H/HW-D Series User’s Guide
Chapter 3 Wizard Setup for Internet Access 77
The following table describes the labels in this screen.
5 Click Apply to save your wireless LAN settings.
Figure 35 Wireless LAN Setup 3
6 Use the read-only summary table to check whether what you have configured is correct.
Click Finish to complete and save the wizard setup.
Table 18 Manually assign a WEP key
LABEL DESCRIPTION
Key The WEP keys are used to encrypt data. Both the ZyXEL Device and the wireless
stations must use the same WEP key for data transmission.
Enter any 5, 13 or 29 ASCII characters or 10, 26 or 58 hexadecimal characters ("0-9",
"A-F") for a 64-bit, 128-bit or 256-bit WEP key respectively.
Back Click Back to display the previous screen.
Next Click Next to proceed to the next screen.
Exit Click Exit to close the wizard screen without saving.
