P-662H/HW-D Series User’s Guide
48
Chapter 1 Getting To Know Your ZyXEL Device
Refer to the Quick Start Guide for information on hardware connections.
WLAN (P-
662HW only)
Green
On
The ZyXEL Device is ready, but is not sending/receiving data
through the wireless LAN.
Blinking
The ZyXEL Device is sending/receiving data through the
wireless LAN.
None
Off
The wireless LAN is not ready or has failed.
DSL/ACT
Green
On
The ZyXEL Device has a successful DSL connection.
Blinking
The DSL is attempting to synchronize with the ZyXEL
Device.
Off
The system is not receiving power or there is no DSL
connection.
INTERNET
Green
On
The ZyXEL Device is connected with no traffic detected.
Blinking
The ZyXEL Device is sending/receiving data.
Red
On
The ZyXEL Device failed to authenticate.
Off
The DSL line is down.
CON/AUX
Green
On
The CON/AUX switch is set to CON, the CON/AUX port is
connected to a management computer and someone is
logged into the ZyXEL Device.
Amber
On
The CON/AUX switch is set to AUX and the CON/AUX port
has an Internet connection through a dial-up modem.
Blinking
The CON/AUX switch is set to AUX and the CON/AUX port is
sending or receiving data through a dial-up modem or ISDN
TA.
Off
The CON/AUX link is not ready, or has failed.
Table 2 Front Panel LEDs (continued)
LED
COLOR
STATUS
DESCRIPTION
