P-662H/HW-D Series User’s Guide
290 Chapter 18 Static Route
Figure 156 Static Route
The following table describes the labels in this screen.
18.2.1 Static Route Edit
Select a static route index number and click Edit. The screen shown next appears. Use this
screen to configure the required information for a static route.
Table 113 Static Route
LABEL DESCRIPTION
# This is the number of an individual static route.
Active This field shows whether this static route is active (Yes) or not (No).
Name This is the name that describes or identifies this route.
Destination This parameter specifies the IP network address of the final destination. Routing is
always based on network number.
Gateway This is the IP address of the gateway. The gateway is a router or switch on the same
network segment as the device's LAN or WAN port. The gateway helps forward
packets to their destinations.
Modify Click the Edit icon to go to the screen where you can set up a static route on the
ZyXEL Device.
Click the Delete icon to remove a static route from the ZyXEL Device. A window
displays asking you to confirm that you want to delete the route.
