P-662H/HW-D Series User’s Guide
Chapter 8 DMZ 153
8.3 DMZ Public IP Address Example
The following figure shows a simple network setup with public IP addresses on the WAN and
DMZ and private IP addresses on the LAN. Lower case letters represent public IP addresses
(like a.b.c.d for example). The LAN port and connected computers (A through C) use private
IP addresses that are in one subnet. The DMZ port and connected servers (D through F) use
public IP addresses that are in another subnet. The public IP addresses of the DMZ and WAN
ports are in separate subnets.
Allow between DMZ
and LAN
Select this check box to forward NetBIOS packets from the LAN to the DMZ and
from the DMZ to the LAN. If your firewall is enabled with the default policy set to
block DMZ to LAN traffic, you also need to enable the default DMZ to LAN firewall
rule that forwards NetBIOS traffic.Clear this check box to block all NetBIOS
packets going from the LAN to the DMZ and from the DMZ to the LAN.
Allow between DMZ
and WAN
Select this check box to forward NetBIOS packets from the WAN to the DMZ and
from the DMZ to the WAN. Clear this check box to block all NetBIOS packets
going from the WAN to the DMZ and from the DMZ to the WAN.
Apply Click Apply to save your changes back to the ZyXEL Device.
Cancel Click Cancel to begin configuring this screen afresh.
Table 51 DMZ (continued)
LABEL DESCRIPTION
