P-662H/HW-D Series User’s Guide
60 Chapter 2 Introducing the Web Configurator
Figure 15 Status: VPN Status
The following table describes the labels in this screen.
2.4.7 Status: Packet Statistics
Click the Packet Statistics hyperlink in the Status screen. Read-only information here
includes port status and packet specific statistics. Also provided are "system up time" and "poll
interval(s)". The Poll Interval(s) field is configurable.
Table 7 Status: VPN Status
LABEL DESCRIPTION
No This is the security association index number.
Name This field displays the identification name for this VPN policy.
Encapsulation This field displays Tunnel or Transport mode.
IPSec
Algorithm
This field displays the security protocol, encryption algorithm, and authentication
algorithm used in each SA.
Disconnect Select one of the security associations, and then click Disconnect to stop that
security association.
Refresh Click Refresh to display the current active VPN connection(s).
