Prestige 480 Dual BRI ISDN Router
Internet Access 3-13
Table 3-4 Internet Access Setup Menu Fields
Field Description
ISP’s Name Enter the name of your Internet Service Provider, e.g., myISP. This
information is for identification purposes only.
Pri Phone and Sec Phone
Number Both the Primary and the Secondary Phone number refer to the number
that the Prestige dials to connect to the ISP.
My Login Name Enter the login name given to you by your ISP.
My Password Enter the password associated with the login name above.
Single User Account Please see the following section for a more detailed discussion on the
Single User Account feature. The default is Yes.
IP Address If your ISP did not assign you a static IP address, enter [0.0.0.0] here;
otherwise, enter that IP address here.
Telco options Transfer
Type This field specifies the type of connection between the Prestige and this
remote node. Select 64K, or Leased.
Multilink The Prestige uses the PPP Multilane Protocol to bundle multiple links in
a single connection to boost the effective throughput between two nodes.
This option is only available if the transfer type is 64K. See Menu 11.2
for more details.
Idle Timeout This value specifies the number of idle seconds that elapses before the
remote node is automatically disconnected. Idle seconds is the period of
time when no data is transmitted from your Prestige. Administrative
packets such as RIP are not counted as data. The default is 100
seconds. This option only applies when the Prestige initiates the call.
At this point, the SMT will ask if you wish to test the Internet connection. If you select Yes, your Prestige
will call the ISP to test the Internet connection. If the test fails, note the error message that you receive on the
screen and take the appropriate troubleshooting steps.
