Prestige 480 Dual BRI ISDN Router

System Maintenance

13-3

If you enter 9 in the Press Command field you will see the following menu:

Figure 13-3 Menu 24.1 after Toggle Status

The following table describes the fields present in Menu 24.1 - System Maintenance - Status . It should be

noted that these fields are READ-ONLY and are meant to be used for diagnostic purposes.

Table 13-1 System Maintenance - Status Menu Fields

Field

Description

ISDN

Shows which ISDN line(s) is in use.

Chan

Shows statistics for B1 and B2 channels respectively. This is the information
displayed for each channel:

Status

Shows the status of the ISDN Channel.

LCP UP indicates that PPP negotiation is taking place. If the negotiation is
successful the ISDN Channel is connected to a Remote Node, otherwise the
connection is Down. Idle, Dial and Answering refer to the status of the ISDN
channel.

Menu 24.1 - System Maintenance - Status 09:59:41
Fri. May. 28, 1999

ISDN

--
--

Chan

--
--

Status

Down
Down

Down

Speed

0kbps
0kbps

0kbps

TxPkts

RxPkts

0
0

Errors

0
0

CLU

0%
0%

ALU

0%
0%

Up Time

0:00:00
0:00:00

0.00.00

ISDN

Chan

Own IP

Own CLID

Peer IP

Peer CLID

Total Outcall Time: 0:00:00 CPU Load = 7.92%

Press Command:

COMMANDS: 1 -Drop ISDN_1 B1 2-Drop ISDN_1 B2 3-Drop ISDN_2 B1 4-Drop ISDN_2 B2

5-Reset Counters 6-Drop Al l 9-Toggle Status ESC-Exit
