Prestige 480 Dual BRI ISDN Router
Hardware Installation and Setup 2-3
Step 1. Connecting the ISDN lines
Connect the Prestige to the ISDN network using the included ISDN (black) cable. Plug one end of the cable
into the port labeled ISDN BRI and the other to the ISDN wall jack.
Step 2. Connecting Ethernet to your Prestige
Use a Unshielded Twisted Pair (UTP) cable and RJ -45 connectors that look like a bigger telephone plug
with eight pins to connect your Prestige to a 10/100M LAN.
Warning: Please verify the correct cable before connecting. If one of these cables is accidentally
used to connect your Prestige to the ISDN lines, it may damage your Prestige.
Step 3. Connecting the Power Adapter to your Prestige
Connect the power adapter to the port labeled POWER on the rear panel of your Prestige.
Step 4. Connecting the Console Port
For the initial configuration of your Prestige, you need to use a terminal emulator software on a workstation
and connect it to the Prestige through the console port . Connect the 9-pin (smaller) end of the console cable
to the console port of the Prestige and the 25-pin (bigger) end to a serial port (COM1, COM2 or other COM
port) of your workstation. You can use an extension RS -232 cable if the enclosed one is too short.
After the initial setup, you can also modify the configuration remotely through telnet connec tions. See the
chapter Telnet Configuration and Capabilities for detailed instructions on using telnet to configure your
Prestige.
2.3 Prestige Network Commander
You can also setup the Prestige using the Prestige Network Commander (PNC). The PNC is a Windows -
based tool that provides a quick and simple way to configure your Prestige. For more information on
installing PNC insert the PNC installation disc in the relevant drive of your computer and follow the on-
screen directions.
