Reference [Rhythm]
ZOOM HD8/HD16 99
3.
Use the cursor left/right keys to bring up the
indication “ORIGINAL ROOT” on the second
line of the display, and press the [ENTER] key.
This screen allows you to specify the root for the selected
rhythm pattern.
4.
Turn the dial to select the root for the chord.
The available range is C – B (default setting: E). When setting
chord information for a rhythm song, the root specified here
will become the default.
5.
When the setting is complete, press the
[EXIT] key.
The rhythm pattern edit menu appears again.
6.
Use the cursor left/right keys to bring up the
indication “ORIGINAL CHORD” on the
second line of the display, and press the
[ENTER] key.
This screen allows you to specify the chord type for the
selected rhythm pattern.
7.
Turn the dial to select the chord.
For the chord type, you can select Major or Minor.
For example, if you have entered a bass phrase with a G major
chord in mind, set the root to “G” and the chord type to
“Major”.
8.
When the setting is complete, press the
[EXIT] key.
The setting is entered and the rhythm pattern edit menu
appears again.
9.
To return to the main screen, press the [EXIT]
key several times.
Normally, the playback volume of the rhythm pattern can be
adjusted with the [RHYTHM] fader for the drum and bass. If
necessary, the volume levels can also be individually
programmed for each rhythm pattern.
1.
From the main screen, hold down the [SHIFT]
key and press pad 7 (PATTERN) so that the
pad lights up.
The rhythm pattern selection screen appears.
2.
Turn the dial to select the rhythm pattern for
which to set the volume, and press the [EDIT]
key.
The rhythm pattern edit menu appears.
3.
Use the cursor left/right keys to bring up the
indication “DRUM LEVEL” on the second line
of the display, and press the [ENTER] key.
This screen allows you to specify the drum sequence volume.
The display shows the current volume setting (1 – 15).
4.
Turn the dial to select the desired setting, and
then press the [EXIT] key.
The setting is entered, and the rhythm pattern edit menu
appears again.
5.
Use the cursor left/right keys to bring up the
indication “BASS LEVEL” on the second line
of the display, and press the [ENTER] key.
This screen allows you to specify the bass sequence volume.
The display shows the current volume setting (1 – 15).
6.
Turn the dial to select the desired setting, and
then press the [EXIT] key.
The setting is entered, and the rhythm pattern edit menu
appears again.
PATTERN EDIT 1/8 PATTERN EDIT 1/8
>QUANTIZE
>QUANTIZE
Original Root Original Root
E
Chord root
Original Chord Original Chord
Major
Major
Changing the drum/bass
sequence volume level
PATTERN EDIT 1/8 PATTERN EDIT 1/8
>QUANTIZE
>QUANTIZE
Drum Level Drum Level
15
15
Bass Level Bass Level
15
15
