Reference [Mixer]
ZOOM HD8/HD16
80
3.
Use the cursor up/down keys to select the
track parameter you want to adjust.
■ Track parameter list
For a list of available parameters for tracks/inputs, see the table
below.
Parameter
Display
Setting range
Description
Mono
track
Stereo
track
Master
track
Drum/
bass track
Input
EQ HI GAIN
(*) (S)
EQ HI G
-12 – +12dB
Adjusts high-frequency boost or cut in
the range from -12 to +12 dB. This
parameter is only shown when HI EQ
is on.
O
O
O
EQ HI
FREQUENCY
(*)
EQ HI F
500 (Hz) – 18
(kHz)
Adjusts turnover frequency for high-
frequency boost/cut. This parameter is
only shown when HI EQ is on.
O
O
O
EQ MID GAIN
(*)
EQ MID G
-12 – +12dB
Adjusts mid-frequency boost or cut in
the range from -12 to +12 dB. This
parameter is only shown when MID
EQ is on.
O
O
O
EQ MID
FREQUENCY
(*)
EQ MID F
40 (Hz) – 18
(kHz)
Adjusts turnover frequency for mid-
frequency boost/cut. This parameter is
only shown when MID EQ is on.
O
O
O
EQ MID Q-
FACTOR (*)
EQ MID Q
0.1 – 1.0
Adjusts the Q value (bandwidth) for
mid-frequency EQ. This parameter is
only shown when MID EQ is on.
O
O
O
EQ LOW
GAIN (*) (S)
EQ LO G
-12 – +12dB
Adjusts low-frequency boost or cut in
the range from -12 to +12 dB. This
parameter is only shown when LOW
EQ is on.
O
O
O
EQ LOW
FREQUENCY
(*)
EQ LO F
40 (Hz) – 1.6
(kHz)
Adjusts turnover frequency for low-
frequency boost/cut. This parameter is
only shown when LOW EQ is on.
O
O
O
CHORUS/
DELAY SEND
LEVEL (*) (S)
DLY SEND
0 – 100
Adjusts the chorus/delay effect send
level for the track/input.
O
O
O
O
REVERB
SEND LEVEL
(*) (S)
REV SEND
0 – 100
Adjusts the reverb effect send level for
the track/input.
O
O
O
O
SUB-OUT
SEND ON/
OFF (*)
SUB SND
On/Off
Selects whether the signal at the
MASTER OUT connectors (master
track signal) is also supplied to the
STEREO SUB-OUT jack.
O
SUB-OUT
SEND LEVEL
(*) (S)
SUB SEND LVL
0 – 127
Adjusts the level of the signal sent from
the track/input to the STEREO SUB-
OUT jack (
→
p. 82).
∆
∆
∆
∆
SUB-OUT
SEND PAN (*)
SUB SND PAN
L100 – R100
Adjusts panning for the signal sent
from the track/input to the STEREO
SUB-OUT jack
∆
∆
∆
∆
PAN (S)
PAN
L100 – R100
Adjusts the panning value of the track/
input signal. For stereo tracks, the
parameter adjusts the left/right level
balance.
O
O
O
O
V-TAKE
Track x-y
x=1 – 8
x=1 – 16
y=1 – 10
Selects the V-take to use for the track
(
→
p. 36). x stands for the track
number and y for the V-take number.
O
O
O
FADER
FADER
0 – 127
Adjusts the current volume level.
O
O
O
O
REC LVL
REC LVL
0 – 127
Adjusts the recording level.
O
STEREO
LINK
ST LINK
On/Off
Controls the stereo link function for
linking two mono tracks (
→
p. 82).
O
INVERT
INVERT
On/Off
Allows inverting the track/input phase.
When set to Off, the phase is normal.
When set to On, the phase is inverted.
O
O
O
O
Mono tracks: 1 – 6 (HD8), 1 – 8 (HD16)
Stereo tracks: 7/8 (HD8), 9/10 – 15/16 (HD16)
(*): Denotes a parameter that can be switched on and off with the [ENTER] key.
(S): Denotes a parameter that can be selected with the [SELECT] key.
O: Valid parameter for this track/input
∆: The triangle denotes a parameter that is only
displayed when the SUB-OUT SEND LVL ON/
OFF parameter for the master track is Off.
