York ECO2 YPAL 050 - Manual (Page 25)

25
2
JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
GENERAL ARRANGEMENT DRAWING – 050-061 MODELS
LD08295
BOTTOM SUPPLY / BOTTOM RETURN
FIG. 2-4 – GENERAL ARRANGEMENT DRAWING
46.00
60.00
1-1/4" FPT DRAINS BOTH SIDES
39.00
82.00
30.00 DOOR
SWING
CLEARANCE BOTH SIDES
78.00 CLEAR
FOR COIL
PULL
92.00 100.50
AIRFLOW
1.50
339.00
91.00 CLEAR
FOR COIL
PULL
120.00 CLEAR
84.00 CLEAR
170.31
ELECTRICAL
SER
VICE
86.50
67.25
5.50 4.56
136.82
60.00 CLEAR FOR AIR INT
AKE
BOTH SIDES
OA OA
191.19
230.62
5.74
75.58
69.83
CO
DP
FS
CC
_F
EE
FE
T
O
P
VIEW
REAR VIEW
FRONT
VIEW
SIDE VIEW
(LEFT
SIDE)
SECTION DESCRIPTIONS: EE = Economizer FE = Fan Exhaust _F = Filter Segments CC = Cooling Coils FS = Supply Fan DP
= Discharge Plenum
CO = Condenser Section
