145 JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
7
TABLE 7-1 – DEFINITIONS (CONTINUED)
Continued on next page
MENU ITEM DEFINITION
ERV UNOCCUPIED FAN ENABLE
THIS PARAMETER ALLOWS THE EXHAUST FAN TO OPERATE
ANYTIME THE SUPPLY FAN IS ON. THIS FEATURE IS REQUIRED
WHEN AN ENERGY RECOVERY VENTILATOR IS INSTALLED.
THIS FEATURE IS CURRENTLY NOT USED ON THESE UNITS.
EXHAUST DAMPER POSITION FOR EXHAUST
TO TURN OFF
WHEN MODULATING DAMPER EXHAUST IS BEING USED THIS IS
THE POSITION OF THE EXHAUST DAMPER TO TURN OFF THE
EXHAUST FAN
EXHAUST DAMPER POSITION FOR EXHAUST
TO TURN ON
WHEN MODULATING DAMPER EXHAUST IS BEING USED THIS
IS THE POSITION OF THE EXHAUST DAMPER TO TURN ON THE
EXHAUST FAN
EXHAUST FAN OUTPUT
THIS GIVES THE STATUS OF THE BINARY OUTPUT FROM THE
UNIT CONTROLLER TO THE EXHAUST FAN, OFF OR ON
EXHAUST DAMPER / VFD OUTPUT STATUS
THIS GIVES THE STATUS OF THE ANALOG UNIT CONTROLLER
OUTPUT TO THE EXHAUST DAMPER OR EXHAUST FAN VFD IN
%
EXHAUST VFD INSTALLED
THIS PARAMETER IDENTIFIES TO THE UNIT CONTROLLER THAT
AN EXHAUST FAN VFD IS INSTALLED. THE PARAMETER MUST
BE TURNED ON TO ENABLE THIS FEATURE
FAN (G) THERMOSTAT INPUT
THIS GIVES THE STATUS OF THE BINARY INPUT TO THE G
TERMINAL OF THE UNIT CONTROLLER, OFF OR ON
FAN ASD TIMER
THIS IS THE STATUS OF THE SUPPLY FAN OFF DELAY IN
SECONDS
FAN OFF DELAY TIMER FOR COOL
THIS GIVES THE STATUS OF THE COOLING TIME OFF DELAY IN
SECONDS
FAN OFF DELAY TIMER FOR HEAT
THIS GIVES THE STATUS OF THE COOLING TIME OFF DELAY IN
SECONDS
FAN ON DELAY TIMER FOR COOL
THIS GIVES THE STATUS OF THE COOLING TIME ON DELAY IN
SECONDS
FAN ON DELAY TIMER FOR HEAT
THIS GIVES THE STATUS OF THE COOLING TIME ON DELAY IN
SECONDS
FREEZE THERMOSTAT SWITCH
THIS IS THE BINARY INPUT FROM THE HYDRONIC HEAT FREEZE
STAT TO THE UNIT CONTROLLER. OFF = FAULTED, ON =
NORMAL OPERATION
GAS VALVE #1
THIS IS THE STATUS OF THE BINARY INPUT FROM THE GAS
VALVE FOR HEAT SECTION 1 TO THE UNIT CONTROLLER OFF /
ON
GAS VALVE #2
THIS IS THE STATUS OF THE BINARY INPUT FROM THE GAS
VALVE FOR HEAT SECTION 2 TO THE UNIT CONTROLLER OFF /
ON
GAS VALVE #3
THIS IS THE STATUS OF THE BINARY INPUT FROM THE GAS
VALVE FOR HEAT SECTION 3 TO THE UNIT CONTROLLER OFF /
ON
HEAT 1 (W1)
THIS IS THE STATUS OF THE BINARY INPUT TO TERMINAL W1
- FIRST STAGE HEATING
HEAT 1 ASCD TIMER
THIS GIVES THE ACTUAL TIME OF THE OFF CYCLE TIMER FOR
HEAT SECTION 1 IN SECONDS.
