Installation
PHYSICAL DATA (CONTINUED)
TABLE 2-6 – PHYSICAL DATA - COMPRESSORS
COMPRESSORS UTILIZED
COMPRESSOR NOMINAL TONS
CAPACITY %
SYSTEM 1
SYSTEM 2
SYSTEM 1
SYSTEM 2
“COMPR
# 1”
“COMPR
# 2”
“COMPR
# 3”
“COMPR
# 4”
“COMPR
# 1”
“COMPR
# 2”
“COMPR
# 3”
“COMPR
# 4”
“STAGE
1”
“STAGE
2”
“STAGE
3”
“STAGE
4”
MODEL
050
ZP137
ZP120
ZP137
ZP120
13.58
12.53
13.58
12.53
26.0
52.0
76.0
100.0
051
ZP137
ZP137
ZP137
ZP137
13.58
13.58
13.58
13.58
25.0
50.0
75.0
100.0
060
ZP182
ZP137
ZP182
ZP137
17.95
13.30
17.95
13.30
28.7
57.4
78.7
100.0
061
ZP182
ZP137
ZP182
ZP154
17.95
13.30
17.60
14.86
28.2
55.8
76.7
100.0
TABLE 2-5 – PHYSICAL DATA - 050-061 MODELS (CONTINUED)
UNIT SIZE
050
051
060
061
FILTERS - 2” PLEATED, 30% EFFICIENT (PRE-FILTER POSITION)
QUANTITY
8 / 12
8 / 12
8 / 12
8 / 12
SIZE (LENGTH X WIDTH) (IN.)
25X16 / 25X20
25X16 / 25X20
25X16 / 25X20
25X16 / 25X20
TOTAL FILTER FACE AREA (SQUARE FEET)
63.9
63.9
63.9
63.9
FILTERS -12” RIGID 65%, 2” 30% PREFILTER (PRE-FILTER POSITION)
QUANTITY
1 / 4 / 9
1 / 4 / 9
1 / 4 / 9
1 / 4 / 9
SIZE (LENGTH X WIDTH) (IN.)
16X20/25X16/
25X20
16X20/25X16/
25X20
16X20/25X16/
25X20
16X20/25X16/
25X20
TOTAL FILTER FACE AREA (SQUARE FEET)
43.0
43.0
43.0
43.0
FILTERS -12” RIGID 95%, 2” 30% PREFILTER (PRE-FILTER POSITION)
QUANTITY
1 / 4 / 9
1 / 4 / 9
1 / 4 / 9
1 / 4 / 9
SIZE (LENGTH X WIDTH) (IN.)
16X20/25X16/
25X20
16X20/25X16/
25X20
16X20/25X16/
25X20
16X20/25X16/
25X20
TOTAL FILTER FACE AREA (SQUARE FEET)
44.6
44.6
44.6
44.6
FILTERS - 2” CARBON (PRE-FILTER POSITION)
QUANTITY
8 / 12
8 / 12
8 / 12
8 / 12
SIZE (LENGTH X WIDTH) (IN.)
25X16 / 25X20
25X16 / 25X20
25X16 / 25X20
25X16 / 25X20
TOTAL FILTER FACE AREA (SQUARE FEET)
63.9
63.9
63.9
63.9
FILTERS - 12” RIGID 95% IN POST-FILTER POSITION
QUANTITY
1 / 3 / 9
1 / 3 / 9
1 / 3 / 9
1 / 3 / 9
SIZE (LENGTH X WIDTH) (IN.)
16X20/25X16/
25X20
16X20/25X16/
25X20
16X20/25X16/
25X20
16X20/25X16/
25X20
TOTAL FILTER FACE AREA (SQUARE FEET)
41.8
41.8
41.8
41.8
GAS FURNACES
STAGED FURNACE SIZES (INPUT/OUTPUT/STEPS)
375 MBH / 300 MBH / 1 STEP
750 MBH / 600 MBH / 2 STEPS
1125 MBH / 900 MBH / 3 STEPS
GAS PRESSURE RANGE
4.5-13.5" WC
4.5-13.5" WC
4.5-13.5" WC
4.5-13.5" WC
AIRFLOW RANGE
(MIN HEATING)
375 MBH
7,500
7,500
11,500
11,500
750 MBH
14,000
14,000
14,000
14,000
1125 MBH
21,000
21,000
21,000
21,000
MINIMUM OA TEMP FOR MECH. CIG.
40.0 °F
40.0 °F
40.0 °F
40.0 °F
LOW AMBIENT OPTION MIN. OA TEMP
0.0 °F
0.0 °F
0.0 °F
0.0 °F
