143 JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
7
Continued on next page
TABLE 7-1 – DEFINITIONS (CONTINUED)
MENU ITEM DEFINITION
COOL FAN OFF DELAY
IN THE INTERMITTENT FAN MODE THIS IS THE TIME DELAY
BETWEEN THE TIME THE COOLING CALL IS TERMINATED AND
THE SHUT DOWN OF THE SUPPLY FAN
COOL FAN ON DELAY
IN THE INTERMITTENT FAN MODE THIS IS THE TIME DELAY
BETWEEN THE TIME THE COOLING CALL IS INITIATED AND THE
START OF THE SUPPLY FAN
COOLING MODE OPERATION ENABLE
THIS PARAMETER MUST BE TURNED ON TO ALLOW COOLING
OPERATION
COOL 1 (Y1)
THIS IS THE STATUS OF THE BINARY INPUT TO TERMINAL Y1
- FIRST STAGE COOLING
COOL 2 (Y2)
THIS IS THE STATUS OF THE BINARY INPUT TO TERMINAL Y2
- SECOND STAGE COOLING
COOL 3 (Y3)
THIS IS THE STATUS OF THE BINARY INPUT TO TERMINAL Y3
- THIRD STAGE COOLING
COOL 4 (Y4)
THIS IS THE STATUS OF THE BINARY INPUT TO TERMINAL Y4
- FOURTH STAGE COOLING
CURRENT BUS ADDRESS
THIS IDENTIFIES THE ADDRESS OF THE UNIT ON THE
NETWORK
CV CURRENT OPERATING COOLING SETPOINT
THIS PARAMETER IDENTIFIES THE COOLING SET POINT THE
UNIT CONTROLLER IS CONTROLLING TO COOLING TOO
CV CURRENT OPERATING HEATING SETPOINT
THIS PARAMETER IDENTIFIES THE HEATING SET POINT THE
UNIT CONTROLLER IS CONTROLLING TO HEATING TOO
CV OCCUPIED COOLING SET POINT
THIS IS THE SPACE OR RETURN AIR TEMPERATURE THE UNIT
WILL CONTROL TO WHEN IN THE OCCUPIED COOLING MODE.
CV OCCUPIED HEATING SET POINT
THIS IS THE SPACE OR RETURN AIR TEMPERATURE THE UNIT
WILL CONTROL TO WHEN IN THE OCCUPIED HEATING MODE.
CV UNOCCUPIED COOLING SET POINT
THIS IS THE SPACE OR RETURN AIR TEMPERATURE THE UNIT
WILL CONTROL TO WHEN IN THE UNOCCUPIED COOLING
MODE.
CV UNOCCUPIED HEATING SET POINT
THIS IS THE SPACE OR RETURN AIR TEMPERATURE THE UNIT
WILL CONTROL TO WHEN IN THE UNOCCUPIED HEATING MODE.
DAY OF MONTH
THIS PARAMETER IS USED TO ENTER THE CURRENT DAY OF
THE MONTH, 1 - 31
DAY OF WEEK
THIS PARAMETER IS USED TO ENTER THE DAY OF THE WEEK
(1-7) WITH 1 EQUAL TO SUNDAY
DEMAND VENTILATION (IAQ) ENABLED
THIS PARAMETER MUST BE TURNED ON TO ENABLE DEMAND
VENTILATION. DEMAND VENTILATION INCREASE THE AMOUNT
OF VENTILATION AIR IN RESPONSE TO A INCREASE IN THE CO2
LEVEL IN THE CONDITIONED SPACE
DEMAND VENTILATION (IAQ) VALUE (CO2) THIS THE CO2 INPUT VALUE TO THE UNIT CONTROLLER IN PPM
DIFFERENTIAL ENTHALPY MODE ENABLED
THIS PARAMETER MUST BE TURNED ON IN ORDER TO USE
DIFFERENTIAL ENTHALPY
DIRTY FILTER SWITCH DATA
THIS PARAMETER GIVE THE STATUS OF THE DIRTY FILTER
SWITCH, 0 = CLEAN, 1 = DIRTY
