108 JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
User Interface Control Center
2. Click on the “Add” button and a dialog box will
appear as shown below.
Left click on Add button
3. In the “Connection Type” dialog box, select “Se-
rial/USB Direct Connection”. Click on the “Port
Number” pull down box and select the computer
port on the computer that the network is connected
to. The port number in the connection box will
vary depending upon the particular computer used
and what port connection it uses or has available.
You can also use the “Connection Name” box to
identify the unit.
3a. Select Serial/USB
direct Connection
3b. Select proper
4. Click Add button
Port Number
LD13040
LD13041
