JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
User Interface Control Center
TABLE - 6-2 - SIMPLICITY ELITE DATA MAP (CONT.)
Continued on next page
ADDRESS
(HEX)
ADDRESS
(DEC)
BIT
INITIAL/
DEFAULT
VALUE
(HEX)
MIN
VALUE
MAX
VALUE
DESCRIPTION
1F H
31 H
NA
0
0
255
COMPRESSOR #1 ACCUMULATED RUN TIME (HOURS, HIGH
BYTE)
1F L
31 L
NA
0
0
255
COMPRESSOR #1 ACCUMULATED RUN TIME (HOURS, LOW BYTE)
20 H
32 H
NA
0
0
255
COMPRESSOR #2 ACCUMULATED RUN TIME (HOURS, HIGH
BYTE)
20 L
32 L
NA
0
0
255
COMPRESSOR #2 ACCUMULATED RUN TIME (HOURS, LOW BYTE)
21 H
33 H
NA
0
0
255
COMPRESSOR #3 ACCUMULATED RUN TIME (HOURS, HIGH
BYTE)
21 L
33 L
NA
0
0
255
COMPRESSOR #3 ACCUMULATED RUN TIME (HOURS, LOW BYTE)
22 H
34 H
NA
0
0
255
COMPRESSOR #4 ACCUMULATED RUN TIME (HOURS, HIGH
BYTE)
22 L
34 L
NA
0
0
255
COMPRESSOR #4 ACCUMULATED RUN TIME (HOURS, LOW BYTE)
24 H
36 H
NA
1
1
250
REQUESTED ADDRESS CHANGE (BUS ADDRESS)
26 L
38 L
NA
NA
NA
NA
REQUESTED OPERATION
0
1 = REQUEST FOR 1ST STAGE COOLING
1
1 = REQUEST FOR 2ND STAGE COOLING
2
1 = REQUEST FOR 3RD STAGE COOLING
3
1 = REQUEST FOR 4TH STAGE COOLING
4
1 = REQUEST FOR 1ST STAGE HEATING
5
1 = REQUEST FOR 2ND STAGE HEATING
6
1 = REQUEST FOR 3RD STAGE HEATING
7
1 = REQUEST FOR FAN
27 H - 33 L
39 H - 51
L
NA
REGISTERS 39 - 51 STORE THE MODEL NUMBER. WHEN
WRITTEN, ALL 13 REGISTERS (AT 2 BYTES PER REGISTER)
SHOULD BE WRITTEN. THE FORMAT IS ASCII. CHARACTER #1
IS IN 39 H. CHARACTER #2 IS IN 39 L. CHARACTER #3 IS IN 40 H,
AND SO ON.
34 H - 40 L
52 H - 64
L
NA
REGISTERS 52 - 64 STORE THE SERIAL NUMBER. WHEN
WRITTEN, ALL 13 REGISTERS (AT 2 BYTES PER REGISTER)
SHOULD BE WRITTEN. THE FORMAT IS ASCII. CHARACTER #1
IS IN 52 H. CHARACTER #2 IS IN 52 L. CHARACTER #3 IS IN 53 H,
AND SO ON.
41 L
65 L
NA
NA
NA
NA
REDLINE/LOADSHED STATUS (5 MINUTE TIMER IS STARTED
EACH WRITE. VALUE IS CLEARED IF TIMER IS ALLOWED TO
FINISH.)
0
1 = SET REDLINE OPERATION
1
1 = SET LOADSHED OPERATION
2 - 7
BITS 2-7 UNUSED
42 L
66 L
255
CLEAR LOCKOUT STATUS
WRITE “00” TO CLEAR ALL LOCKOUTS. ANY OTHER VALUE IS
IGNORED. ALWAYS READS 255.
43 H
67 H
-
0
255
READING THIS ADDRESS RETURNS EEPROM CHECKSUM HIGH
BYTE
