101 JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
6
TABLE 6-1 - PARAMETER POINTS LIST
ADDRESS
NUMBER
DESCRIPTION UNITS OF ADJUSTMENT
RANGE OF
ADJUSTMENT
CURRENT
SETTING
1 RUN TEST PARAMETER BIT 0 = OFF, 1 = ON OFF
2 HEAT FAN ON DELAY SECONDS 0-30 30
3 HEAT FAN OFF DELAY SECONDS 0-255 60
4 COOL FAN ON DELAY SECONDS 0-30 0
5 COOL FAN OFF DELAY SECONDS 0-255 30
6 ADDRESS DATA 1-250 1
7 TURN OFF CONTINUOUS FAN WHEN STARTING PARAMETER BIT 0 = OFF, 1 = ON OFF
8 CONSTRUCTION MODE PARAMETER BIT 0 = OFF, 1 = ON OFF
9 UNOCCUPIED OVERRIDE TIME PERIOD DATA MINUTES
0-240
0 = DISABLED
60
MINUTES
10 CV OCCUPIED COOLING SETPOINT DEGREES F 45º - 99º 72º
11 CV OCCUPIED HEATING SETPOINT DEGREES F 45º - 99º 68º
12 CV UNOCCUPIED COOLING SETPOINT DEGREES F 45º - 99º 85º
13 CV UNOCCUPIED HEATING SETPOINT DEGREES F 45º - 99º 60º
14 SUPPLY AIR TEMP LIMIT FOR COOLING ENABLE PARAMETER BIT 0 = OFF, 1 = ON ON
15 SUPPLY AIR TEMP LIMIT COOLING SETPOINT DEGREES F 40º - 65º 50º
16 SUPPLY AIR TEMP LIMIT FOR HEATING ENABLED PARAMETER BIT 0 = OFF, 1 = ON ON
17 SUPPLY AIR TEMP LIMIT HEATING SETPOINT DEGREES F 100º - 180º 135º
18 HYDRONIC HEATING ENABLED PARAMETER BIT 0 = OFF, 1 = ON OFF
19
HYDRONIC HEATING STAGE #1 SUPPLY AIR
SETPOINT
DEGREES F 80º - 180º 120º
20
HYDRONIC HEATING STAGE #2 SUPPLY AIR
SETPOINT
DEGREES F 80º - 180º 150º
21
HYDRONIC HEAT ACTUATOR VALVE REVERSE
ACTING
PARAMETER BIT 0 = OFF, 1 = ON OFF
22
REMOTE CONTROL INPUT ENABLE FOR THIRD
PARTY BAS
PARAMETER BIT 0 = OFF, 1 = ON OFF
23
VAV COOLING SUPPLY AIR TEMP UPPER
SETPOINT
DEGREES F 40º - 70º 60º
24
VAV COOLING SUPPLY AIR TEMP LOWER
SETPOINT
DEGREES F 40º - 70º 55º
25 VAV SUPPLY AIR TEMP RESET SETPOINT DEGREES F 40º - 85º 72º
26 VAV OCCUPIED HEATING ENABLED PARAMETER BIT 0 = OFF, 1 = ON OFF
27 VAV OCCUPIED HEATING SETPOINT DEGREES F 40º - 85º 68º
28 MORNING WARM-UP ENABLE PARAMETER BIT 0 = OFF, 1 = ON ON
29
MORNING WARM-UP / VAV RETURN AIR TEMP
SETPOINT
DEGREES F 50º - 85º 70º
30 DUCT PRESSURE SETPOINT
PRESSURE - INCHES OF
H2O
0.000 - 5.000 1.500
31 BUILDING PRESSURE SETPOINT
PRESSURE - INCHES OF
H2O
-.250 -.250 0.1
32 ECONOMIZER INSTALLED PARAMETER BIT 0 = OFF, 1 = ON ON
33 ECONOMIZER FIRST STAGE SETPOINT DEGREES F 40º - 65º 55º
34 ECONOMIZER SECOND STAGE SETPOINT DEGREES F 40º - 65º 50º
35 ECONOMIZER MINIMUM POSITION PERCENT 0 - 100% 20%
Continued on next page
