146 JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
Parameter Description and Options
TABLE 7-1 – DEFINITIONS (CONTINUED)
Continued on next page
MENU ITEM DEFINITION
HEAT 1 MIN RUN TIMER
THIS GIVES THE ACTUAL TIME OF THE MINIMUM RUN TIME
TIMER FOR HEAT SECTION 1 IN SECONDS
HEAT 2 (W2)
THIS IS THE STATUS OF THE BINARY INPUT TO TERMINAL W2
- SECOND STAGE HEATING
HEAT 2 ASCD TIMER
THIS GIVES THE ACTUAL TIME OF THE OFF CYCLE TIMER FOR
HEAT SECTION 2 IN SECONDS.
HEAT 2 MIN RUN TIMER
THIS GIVES THE ACTUAL TIME OF THE MINIMUM RUN TIME
TIMER FOR HEAT SECTION 2 IN SECONDS
HEAT 3 (W3)
THIS IS THE STATUS OF THE BINARY INPUT TO TERMINAL W3
- THIRD STAGE HEATING
HEAT 3 ASCD TIMER
THIS GIVES THE ACTUAL TIME OF THE OFF CYCLE TIMER FOR
HEAT SECTION 3 IN SECONDS.
HEAT 3 MIN RUN TIMER
THIS GIVES THE ACTUAL TIME OF THE MINIMUM RUN TIME
TIMER FOR HEAT SECTION 3 IN SECONDS
HEAT FAN OFF DELAY
IN THE INTERMITTENT FAN MODE THIS IS THE TIME DELAY
BETWEEN THE TIME THE HEAT CALL IS TERMINATED AND THE
SHUT DOWN OF THE SUPPLY FAN
HEAT FAN ON DELAY
IN THE INTERMITTENT FAN MODE THIS IS THE TIME DELAY
BETWEEN THE TIME THE HEATING OPERATION IS VERIFIED
AND THE START OF SUPPLY FAN OPERATION
HEATING MODE ENABLED FOR OPERATION
THIS PARAMETER MUST BE TURNED ON TO ALLOW HEATING
OPERATION
HEATING NUMBER #1 ACCUMULATED RUNTIME
THIS IS THE NUMBER OF HOURS THAT HEATING SYSTEM 1 HAS
BEEN OPERATIVE
HEATING NUMBER #2 ACCUMULATED RUNTIME
THIS IS THE NUMBER OF HOURS THAT HEATING SYSTEM 2 HAS
BEEN OPERATIVE
HEATING NUMBER #3 ACCUMULATED RUNTIME
THIS IS THE NUMBER OF HOURS THAT HEATING SYSTEM 3 HAS
BEEN OPERATIVE
HEATING OUTPUT #1 (H1)
THIS IS THE STATUS OF THE BINARY OUTPUT FROM THE UNIT
CONTROLLER TO HEAT SECTION # 1, OFF/ON
HEATING OUTPUT #2 (H2)
THIS IS THE STATUS OF THE BINARY OUTPUT FROM THE UNIT
CONTROLLER TO HEAT SECTION # 2, OFF/ON
HEATING OUTPUT #3 (H3)
THIS IS THE STATUS OF THE BINARY OUTPUT FROM THE UNIT
CONTROLLER TO HEAT SECTION # 3, OFF/ON
HOT GAS PRESENT ON COMPRESSOR # 1
THIS PARAMETER MUST BE TURNED ON WHEN HOT GAS
BYPASS IS INSTALLED
HOT GAS REHEAT
THIS PARAMETER WOULD BE TURNED ON TO ENABLE HOT GAS
REHEAT. THIS FEATURE IS NOT AVAILABLE ON THESE UNITS
HOT WATER VALVE OUTPUT STATUS
THIS GIVES THE STATUS OF THE ANALOG UNIT CONTROLLER
OUTPUT TO THE HYDRONIC VALVE IN %
HOT WATER VALVE OUTPUT STATUS
(REVERSE ACTING)
THIS GIVES THE STATUS OF THE ANALOG UNIT CONTROLLER
OUTPUT TO THE HYDRONIC VALVE IN % WHEN THE UNIT IS
PROGRAMMED FOR A REVERSE ACTING VALVE
HOUR
THIS PARAMETER IS USED TO ENTER THE HOUR OF THE
CURRENT TIME BASED ON A 24 HOUR SCHEDULE, 13 WOULD
BE 1 PM
