140 JOHNSON CONTROLS
FORM 100.50-NOM6 (1207)
User Interface Control Center
TABLE - 6-2 - SIMPLICITY ELITE DATA MAP (CONT.)
ADDRESS
(HEX)
ADDRESS
(DEC)
BIT
INITIAL/
DEFAULT
VALUE
(HEX)
MIN
VALUE
MAX
VALUE
DESCRIPTION
D7L 215 L NA 0 - - OPTION BYTE #7
0 1 = ERV ENABLED
1 1 = ERV UNOCCUPIED FAN ENABLED
2-7 NA
D8 H 216 H S 0 100 HOT GAS REHEAT HUMIDITY SETPOINT (PERCENT HUMIDITY)
D8 L 216 L 50 20 80 TEMPERATURE / HUMIDITY SETPOINT (PERCENT HUMIDITY)
D9 H 217 H 3 0 5 MAXIMUM TEMPERATURE / HUMIDITY OFFSET (DEGREES F)
D9 L 217 L 5 1 10
TEMPERATURE / HUMIDITY VALUE THAT = 1° F OF OFFSET
(PERCENT HUMIDITY)
DB H 219 H 72 45 99 OPERATING COOLING SETPOINT (DEGREES F) [CV]
DB L 219 L 68 45 99 OPERATING HEATING SETPOINT (DEGREES F) [CV]
DC H 220 H - 10 50 OUTSIDE AIR ENTHALPY (BTUS PER POUND)
DC L 220 L - 10 50 RETURN AIR ENTHALPY (BTUS PER POUND)
DE L 222 L 50 0 100
MAXIMUM DEMAND VENTILATION ECONOMIZER POSITION
(PERCENT OPEN)
DF H 223 H - 0 10 SPACE SENSOR OFFSET (0 = -5° F, 10 = +5° F)
E0 H 224 H - - -
ASCD TIMER FOR HEATING STAGE #1 (SECONDS, COUNTS
DOWN)
E0 L 224 L - - -
HEATING STAGE #1 MINIMUM RUN TIMER (SECONDS, COUNTS
DOWN)
E1 H 225 H - - -
ASCD TIMER FOR HEATING STAGE #2 (SECONDS, COUNTS
DOWN)
E1 L 225 L - - -
HEATING STAGE #2 MINIMUM RUN TIMER (SECONDS, COUNTS
DOWN)
E2 H 226 H - - -
ASCD TIMER FOR HEATING STAGE #3 (SECONDS, COUNTS
DOWN)
E2 L 226 L - - -
HEATING STAGE #3 MINIMUM RUN TIMER (SECONDS, COUNTS
DOWN)
E3 H 227 H 0 0 99 LOW AMBIENT ECONOMIZER MINIMUM POSITION (PERCENT)
E3 L 227 L 0 0 60 LOW AMBIENT ECONOMIZER SETPOINT (DEGREES F)
