- 14 -
Installation
Date en cours : 11 août 2004
\\Sct01002\BE31-DOC\DOC 31 - En cours\Travaux en cours\Fax\MFL V 2\LU 251 523 984B MFL_V2 FAXCENTRE F116_F116L XEROX
FR_GB_ESP\Anglais\Installation.fm
D
ESCRIPTION
Control panel
Document output
tray
Copy output tray
machine
Paper feed tray
Second paper
cassette (option)
Scanner
AC power
Drum cartridge
(pre-installed)
Toner Cartridge
(pre-installed)
L1 telephone line
cable
AC power
cord
Adjustable
paper guide
Top cover release
button
Machine cover
release button
On/Off
switch
Second cassette
paper tray
(500 pages)
Chip card
reader
L1 telephone
cable socket
(option)
L2 telepbone
cable socket
(model F116L)
L2 telephone line
cable
(model F116L)
Document feed
tray for scanning
connector
