Clear the paper misfeed using one of the following procedures depending upon the location
of the paper misfeed.
Between the drum cartridge and the fusing assembly
NOTE : Do not touch the image transfer roller (black roller at the bottom of the machine).
Reinstall the drum cartridge and the toner cartridge (refer to paragraph Replacing
cartridges, page 96).
