10 Problem Solving
180
Pr
ob
le
m Solving
10
Paper Jams in Upper Unit
The following describes how to clear paper jams that occur in the upper unit.
1
Lift up the upper unit release lever to open the
upper unit.
2 Check the state of the jammed paper, and solve the problem as follows.
„ The following message is displayed.
Remove the jammed paper through the opening
area from the machine.
Important • Never touch a labeled area found on hot or
sharp parts. You can get burned or injured.
• Gently remove the paper taking care not to
tear it.
• If the paper is torn, make sure to remove all
torn paper from the machine.
Upper Unit Releasing Lever
