ZyWALL 2 and ZyWALL 2WE
7-8 LAN Setup
Table 7-4 LAN TCP/IP Setup Menu Fields
FIELD DESCRIPTION EXAMPLE
Version Press [SPACE BAR] and then [ENTER] to select the RIP version.
Options are:
RIP-1, RIP-2B or RIP-2M. RIP-1
(default)
Multicast IGMP (Internet Group Multicast Protocol) is a session-layer
protocol used to establish membership in a Multicast group. The
ZyWALL supports both IGMP version 1 (IGMP-v1) and version 2
(IGMP-v2). Press [SPACE BAR] and then [ENTER] to enable IP
Multicasting or select None (default) to disable it. None
Edit IP Alias The ZyWALL supports three logical LAN interfaces via its single
physical Ethernet interface with the ZyWALL itself as the gateway
for each LAN network. Press [SPACE BAR] to select Yes and then
press [ENTER] to display menu 3.2.1 Yes
IP Policies You can apply up to four IP Policy sets (from twelve) by typing
their numbers separated by commas. 2,7,9,11
When you have completed this menu, press [ENTER] at the prompt [Press ENTER to Confirm…] to save
your configuration, or press [ESC] at any time to cancel.
7.5.1 IP Alias Setup
You must use menu 3.2 to configure the first network. Move the cursor to the Edit IP Alias field, press
[SPACE BAR] to choose Yes and press [ENTER] to configure the second and third network.
Press [ENTER] to open Menu 3.2.1 - IP Alias Setup, as shown next.
